| initial | 3 days later | 7 days later | 15 days later | ||
|---|---|---|---|---|---|
| HX-3722 ※1 | 30phr | 18.4 | 18.5 | 18.5 | 18.5 |
| HX-3742 ※1 | 30phr | 18.4 | 18.2 | 18.2 | 18.3 |
| HX-3088 ※1 | 30phr | 18.1 | 18.0 | 18.1 | 18.1 |
| Non capsulized hardener ※2 | 20phr | 24.5 | 31.0 | 35.4 | 56.3 |
| Grade |
Mean particle size ［um］ |
Capsule thickness |
Feature |
Viscosity ［Pa・s］ |
Gel time (Resin composition) ［min］ |
||
|---|---|---|---|---|---|---|---|
| 90℃ | 130℃ | 170℃ | |||||
| HX-3722 | 2 | Thin | Low temp,(80℃〜) and rapid cure | 100～500 | 11 | 1 | <1 |
| HX-3742 | 2 | Thick | Long pot life(with acid anhydride) | 200～600 | >30 | >30 | <1 |
| HX-3088 | 2 | Ex-thick | Long pot life(with acid anhydride) | 200～700 | >30 | >30 | >30 |
| HX-3921HP | 5 | Thin |
Low temp,rapid cure Low chlorine type |
50～130 | 11 | 1 | <1 |
| HX-3941HP | 5 | Thick |
Long pot life / solvent stable Low chlorine type |
50～250 | >30 | <1 | <1 |
| HXA3922HP | 2 | Thin |
Low temp,rapid cure Low chlorine type |
70～200 | 14 | 1 | <1 |
| HXA3932HP | 2 | Thick |
Long pot life / solvent stable Low chlorine type |
50～200 | >30 | 1 | <1 |
上述是典型等级，如果您对粘度和硬化开始温度等有要求，请与我们联系。
※Liquid BisA type epoxy resin(EEW:180g/eq)：能覇旭＝100：30 (本公司推荐的配比)
